Elasticsearch Vertical Scaling

This guide will give an overview on how KubeDB Ops-manager operator updates the resources(for example CPU and Memory etc.) of the Elasticsearch.

Before You Begin

• You should be familiar with the following KubeDB concepts:
• Elasticsearch
• ElasticsearchOpsRequest

How Vertical Scaling Process Works

The following diagram shows how KubeDB Ops-manager operator updates the resources of the Elasticsearch. Open the image in a new tab to see the enlarged version.

  

The vertical scaling process consists of the following steps:

1. At first, a user creates a Elasticsearch Custom Resource (CR).

2. KubeDB Provisioner operator watches the Elasticsearch CR.

3. When the operator finds a Elasticsearch CR, it creates required number of PetSets and related necessary stuff like secrets, services, etc.

4. Then, in order to update the resources(for example CPU, Memory etc.) of the Elasticsearch cluster, the user creates a ElasticsearchOpsRequest CR with desired information.

5. KubeDB Ops-manager operator watches the ElasticsearchOpsRequest CR.

6. When it finds a ElasticsearchOpsRequest CR, it halts the Elasticsearch object which is referred from the ElasticsearchOpsRequest. So, the KubeDB Provisioner operator doesn’t perform any operations on the Elasticsearch object during the vertical scaling process.

7. Then the KubeDB Ops-manager operator will update resources of the PetSet Pods to reach desired state.

8. After the successful update of the resources of the PetSet’s replica, the KubeDB Ops-manager operator updates the Elasticsearch object to reflect the updated state.

9. After the successful update of the Elasticsearch resources, the KubeDB Ops-manager operator resumes the Elasticsearch object so that the KubeDB Provisioner operator resumes its usual operations.

In the next docs, we are going to show a step by step guide on updating resources of Elasticsearch database using ElasticsearchOpsRequest CRD.
